2018–2020 Ford F-150 Bulb Size Guide & LED Upgrade Chart

Looking for the correct 2018–2020 Ford F-150 bulb size? This guide covers factory halogen-equipped 2018, 2019 and 2020 Ford F-150 trucks and includes low beam, high beam, fog light, front turn signal, rear brake/turn signal, reverse light, cargo light, third brake light, and license plate light bulb sizes.

The most important thing to check before ordering is your truck's factory headlight configuration. The bulb recommendations in this guide are for F-150 trucks equipped with factory halogen headlights. Trucks equipped with factory LED headlights use integrated LED headlight assemblies and do not use the H11 and 9005 replacement headlight bulbs listed here.

Quick Navigation

• 2018–2020 F-150 Bulb Size Chart
• Halogen vs Factory LED Headlights
• Headlights, Fog Lights & Front Turn Signals
• F-150 Extended Low-Beam Dust Covers
• Rear Lighting Bulb Sizes
• Cargo & Third Brake Lights
• Recommended LED Upgrades
• LED Installation & CANbus Information
• Light Output & Beam Pattern
• Frequently Asked Questions

2018–2020 Ford F-150 Bulb Size Chart

Use the chart below as a quick reference for the replaceable lighting positions covered by this guide.

Factory Halogen vs Factory LED Headlights

The 2018–2020 Ford F-150 was available with different factory headlight configurations. This guide is specifically intended for trucks equipped with replaceable factory halogen headlight bulbs.

Factory Halogen Headlights

Factory halogen-equipped trucks use:

• Low Beam: H11
• High Beam: 9005/HB3

Both positions can be upgraded with compatible FUZED LED bulbs.

Factory LED Headlights

Factory LED-equipped F-150 trucks use an integrated LED headlight assembly rather than conventional replaceable H11 and 9005 halogen bulbs.

If your truck has the factory LED headlight configuration, the H11 low-beam and 9005 high-beam recommendations in this guide do not apply.

2018–2020 Ford F-150 Headlight, Fog Light & Front Turn Signal Bulb Sizes

Low Beam — H11

2018–2020 Ford F-150 trucks equipped with factory halogen headlights use an H11 low-beam bulb.

FUZED LED H11 bulbs provide a direct LED upgrade for the factory halogen bulb. When converting the low beam to LED on these trucks, additional clearance is required behind the bulb, so an extended dust cover must also be installed.

Shop FUZED LED H11 F1 Series Low-Beam Bulbs →

High Beam — 9005 / HB3

The factory halogen high beam uses a 9005/HB3 bulb.

The 9005 is a separate high-beam bulb from the H11 low beam, allowing the two positions to be upgraded independently.

Shop FUZED LED 9005/HB3 F1 Series High-Beam Bulbs →

FUZED LED Headlight Upgrade

Upgrading the factory halogen H11 low beams and 9005/HB3 high beams to compatible FUZED LED bulbs provides brighter, whiter illumination compared with the original halogen lighting.

For best performance, proper bulb installation and LED-chip orientation are important. We cover bulb positioning and beam pattern later in this guide.

Fog Light — 9140 / H10

Factory halogen fog lights on the trucks covered by this guide use a 9140/H10 bulb.

The compatible FUZED LED upgrade uses our 9145/H10 LED fog-light bulb.

Shop FUZED LED 9145/H10 Fog Light Bulbs →

2018 Front Turn Signal — 7444

The 2018 Ford F-150 uses a 7444 front turn-signal bulb.

Our compatible FUZED LED switchback turn-signal bulbs work in this application and provide an LED upgrade for the factory front turn signal.

Shop FUZED LED Switchback Front Turn Signals →

2019–2020 Front Turn Signal — 4257

The 2019 and 2020 Ford F-150 use a 4257 front turn-signal bulb.

FUZED LED does not currently offer an LED replacement for the 4257 front turn-signal application, so the 2018 switchback recommendation should not be used for 2019 or 2020 trucks.

Extended Dust Covers Are Required for the LED Low Beam

When installing an LED bulb in the H11 low-beam position on a factory halogen-equipped 2018–2020 F-150, additional space is required behind the LED bulb.

The original factory low-beam dust cover does not provide enough clearance for the LED cooling assembly. An extended F-150 dust cover provides the additional room needed while allowing the rear of the headlight housing to remain covered.

The H11 LED bulbs and extended dust covers are sold separately, so make sure to order both when converting the factory halogen low beam to LED.

Shop 2015–2020 F-150 Extended LED Dust Covers →

2018–2020 Ford F-150 Rear Lighting Bulb Sizes

Reverse Light — 7440

The reverse-light bulb size is 7440 on the 2018–2020 Ford F-150 applications covered by this guide.

Our FUZED LED 7440 reverse-light upgrade produces 2,100 lumens of bright white output, providing substantially more usable light behind the truck when reversing at night.

Shop FUZED LED 2,100-Lumen 7440 Reverse Lights →

Rear Brake & Turn Signal — 3157

The rear brake and turn-signal bulb size is 3157 on the 2018–2020 F-150 configurations covered by this guide.

FUZED LED does not currently offer a recommended LED upgrade for this rear brake/turn-signal application. We recommend using the correct factory-style bulb rather than installing an unverified LED replacement.

License Plate Light — 194 / 168 / T10

The license plate lights use a 194/168/T10-family bulb.

A white LED upgrade provides a cleaner, modern appearance compared with the factory incandescent license plate lighting.

Shop FUZED LED 194/T10 License Plate Bulbs →

Cargo Light & Third Brake Light Bulb Sizes

Cargo Lights — 921 / T15

The cargo-light positions use 921/T15 bulbs.

Upgrading the cargo lights to brighter white LEDs can provide considerably more usable illumination in the truck bed at night.

Shop FUZED LED White 921 Cargo Light Bulbs →

Third Brake Light — 921 / T15

The third brake-light position also uses a 921/T15-size bulb on the applications covered by this guide.

Because this position is used as a brake light rather than a cargo light, use the appropriate red FUZED LED 921 third-brake-light bulb.

Shop FUZED LED Red 921 Third Brake Light Bulbs →

Recommended FUZED LED Upgrades for the 2018–2020 F-150

For factory halogen-equipped trucks, the main FUZED LED upgrades covered by this guide are:

• Low Beam: H11 FUZED LED
• High Beam: 9005/HB3 FUZED LED
• Fog Lights: 9145/H10 FUZED LED
• 2018 Front Turn Signal: FUZED LED switchback
• Reverse Lights: 7440 2,100-lumen FUZED LED
• Cargo Lights: White 921 FUZED LED
• Third Brake Light: Red 921 FUZED LED
• License Plate Lights: 194/T10 FUZED LED

Remember that the H11 low-beam LED conversion also requires the separate extended F-150 dust covers.

LED Installation & CANbus Information

The compatible FUZED LED products listed in this guide have been tested for the 2018–2020 Ford F-150 applications covered here.

No CANbus decoder is required when using the compatible FUZED LED headlight bulbs on these trucks.

The H11 low beam does require the extended dust cover for physical clearance, but an additional CANbus decoder is not necessary.

Headlight Bulb Access

One way to access the headlight bulbs is through the inner fender-well area. Removing the necessary fasteners allows the inner fender liner to be moved enough to reach the rear of the headlight housing.

Once the H11 LED low-beam bulb is installed, make sure the extended dust cover is securely installed to protect the rear of the headlight assembly.

LED Light Output & Headlight Beam Pattern

A good LED headlight upgrade is about more than maximum lumen output. The LED light source must also be positioned correctly inside the factory headlight so the reflector or projector can direct the light where it is useful.

When installing the compatible FUZED LED H11 low-beam or 9005/HB3 high-beam bulbs, the LED chips should face horizontally from side to side.

Viewed from behind the installed bulb, the LED chips should be positioned at approximately the 3 o'clock and 9 o'clock positions.

After installation, confirm that the bulb is fully seated and locked in place, then check the headlight beam pattern and aim before nighttime driving.

2018–2020 Ford F-150 Bulb Size FAQs

What size low-beam bulb does a 2018–2020 Ford F-150 use?

Factory halogen-equipped 2018–2020 Ford F-150 trucks use an H11 low-beam bulb. Factory LED-equipped trucks use integrated LED headlights and do not use the H11 replacement bulb.

What size high-beam bulb does a 2018–2020 Ford F-150 use?

Factory halogen-equipped trucks use a separate 9005/HB3 high-beam bulb.

Do I need extended dust covers when installing LED low beams?

Yes. When installing the compatible FUZED LED H11 low-beam bulbs, the factory dust cover does not provide enough clearance for the LED cooling assembly. Use the 2015–2020 F-150 extended LED dust covers.

Shop F-150 Extended Dust Covers →

Do FUZED LED headlights require CANbus decoders on the 2018–2020 F-150?

No. Compatible FUZED LED headlight bulbs do not require CANbus decoders on the factory halogen-equipped 2018–2020 F-150 applications covered by this guide.

What fog-light bulb does a 2018–2020 Ford F-150 use?

The factory halogen fog-light application uses a 9140/H10 bulb. The compatible FUZED LED upgrade uses our 9145/H10 LED fog-light bulb.

What front turn-signal bulb does a 2018 Ford F-150 use?

The 2018 Ford F-150 uses a 7444 front turn-signal bulb. A compatible FUZED LED switchback turn-signal upgrade is available for this application.

What front turn-signal bulb does a 2019 or 2020 Ford F-150 use?

The 2019 and 2020 Ford F-150 use a 4257 front turn-signal bulb. FUZED LED does not currently offer an LED replacement for this application.

What size reverse-light bulb does a 2018–2020 Ford F-150 use?

The reverse-light bulb size is 7440. FUZED LED offers a compatible 2,100-lumen 7440 LED reverse-light upgrade for these trucks.

What size rear brake and turn-signal bulb does a 2018–2020 F-150 use?

The rear brake/turn-signal bulb size is 3157. FUZED LED does not currently offer a recommended LED replacement for this rear position.

What size cargo-light bulb does a 2018–2020 F-150 use?

The cargo lights use 921/T15 bulbs. FUZED LED offers bright white 921 LEDs designed for the cargo-light application.

What size third brake-light bulb does a 2018–2020 F-150 use?

The third brake light also uses a 921/T15-size bulb. Use the appropriate red FUZED LED 921 bulb for the third-brake-light position.

What size license plate bulb does a 2018–2020 Ford F-150 use?

The license plate lights use a 194/168/T10-family bulb.

Can I use these H11 and 9005 bulbs if my F-150 has factory LED headlights?

No. The H11 low-beam and 9005/HB3 high-beam recommendations in this guide are for factory halogen-equipped trucks only. Factory LED headlights use integrated LED assemblies rather than these conventional replaceable bulbs.

Before Ordering LED Bulbs for Your 2018–2020 F-150

Before ordering, confirm these important fitment details:

1. Model year: 2018, 2019 or 2020
2. Headlight type: Factory halogen or factory LED
3. Lighting position: Low beam, high beam, fog light, turn signal, reverse, cargo, third brake, or license plate
4. Front turn-signal year: 2018 uses 7444, while 2019–2020 use 4257
5. Low-beam LED installation: H11 LED upgrades require the separate extended dust covers

If your truck has aftermarket headlights, aftermarket tail lights, or modified factory wiring, verify the requirements of those components separately.
